Model No.: D-Think_SL032-2

HF RFID Module, Developed Based on NXP's Low Power Transponder ICs, Measures 46 x 46mm

  • Features:
    • Being developed based on NXP's low power transponder ICs
    • It is a mini Mifare read/write module
    • It supports Mifare 1k/4k, ultra-light and DesFire
    • Its maximum working and sleep current are 45mA and 10uA respectively
    • In addition, it can integrate all necessary components and antenna in one PCB
  • Specification:
    • Frequency: 13.56MHz
    • Tag supported: ultra-light, Mifare mini, 1k, 4k, FM11RF08 and DesFire
    • Interface: UART
    • Supply voltage: 2.5 to 3.6V DC
    • Dimension: 46 x 46mm
